| Memory (RAM) | 1 GB |
| Flash | 512 MB in total. To view the available flash memory size, run the display version command. |
| Mean time between failures (MTBF) | 23.9 years |
| Mean time to repair (MTTR) | 2 hours |
| Availability | > 0.99999 |
| Service port surge protection | Common mode: ±6 kV |
| Power supply surge protection | - Using 580 W AC or 1000 W AC power modules: ±6 kV in differential mode, ±6 kV in common mode
- Using 650 W DC power modules: ±2 kV in differential mode, ±4 kV in common mode
|
| Dimensions (H x W x D) | 44.4 mm x 442.0 mm x 420.0 mm (1.75 in. x 17.4 in. x 16.5 in.) |
| Weight (with packaging) | 9.3 kg (20.5 lb) |
| Stack ports | Any MultiGE, 10GE SFP+, or 40GE QSFP+ ports (a maximum of 16 physical ports) |
| RTC | Supported |
| RPS | Not supported |
| PoE | Supported |
| Rated voltage range | 100 V AC to 240 V AC, 50/60 Hz -48 V DC to -60 V DC |
| Maximum voltage range | 90 V AC to 264 V AC, 47 Hz to 63 Hz -38.4 V DC to -72 V DC |
| Maximum power consumption (100% throughput, full speed of fans) | - Using 650 W DC power modules or 580 W AC power modules
- Not providing the PoE function: 120.5 W (without card)
- 100% PoE loads: 1068.1 W (system power consumption: 328.9 W, PoE: 739.2 W, without card)
- Using 1000 W AC power modules
- Not providing the PoE function: 120.5 W (without card)
- 100% PoE loads: 1995.4 W (system power consumption: 555.4 W, PoE: 1440 W, without card)
|
| Typical power consumption (30% of traffic load, tested according to ATIS standard) | 91.01 W (not providing the PoE function, without card) |
| Operating temperature | 0°C to 45°C (32°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.) |
| Short-term operating temperature | -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5906 ft.) |
| Storage temperature | -40°C to +70°C (-40°F to +158°F) |
| Noise under normal temperature (27°C, sound power) | < 60.5 dB(A) |
| Relative humidity | 5% to 95%, noncondensing |
| Operating altitude | 0-5000 m (0-16404 ft.) |
| Certification | - EMC certification
- Safety certification
- Manufacturing certification
|
| Part number | 98010727 |
