Huawei Router AR169F AR G3 AR160 Series VDSL 1GE COMBO WAN 4GE LAN 1 USB

Name: Huawei Router AR169F AR G3 AR160 Series VDSL 1GE COMBO WAN 4GE LAN 1 USB
Brand: HUAWEI
Price: 1 USD

China Huawei Router AR169F AR G3 AR160 Series VDSL 1GE COMBO WAN 4GE LAN 1 USB wholesale

Brand Name : HUAWEI

Model Number : AR169F

Certification : CE

Place of Origin : CHINA

MOQ : 1 UNIT

Price : Negotiable

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 100 UNITS/MONTH

Delivery Time : 1-2 DAYS

Packaging Details : NEW IN BOX

Part number : AR169F

Brand : Huawei

Interface number : LAN interfaces: GE0-GE3

Extended slots : Not Support

Power module type : External power adapter

Condition : New with 1Year Warranty

Contact Now

Huawei Router AR169F,VDSL over POTS with bonding WAN,1GE COMBO WAN,4GE LAN,1 USB

AR169F Overview

Huawei AR G3 AR160 Series AR169F fixed interface access enterprise router bring good user experience and secure environment, fanless design provide quiet environment.

AR169F Specification

Item	Specification
System parameters
Processor	Dual-core, 533 MHz
Memory	AR169F: 512 MB AR169BF: 1 GB
Flash	512 MB
Micro SD card (default: sd1)	None
Hard disk	Not supported
Physical specifications
Dimensions (H x W x D)	With no mounting bracket installed: 44.0 mm x 300.0 mm x 216.4 mm (1.73 in. x 11.81 in. x 8.52 in.), 1 U height With mounting brackets installed: 44.0 mm x 482.6 mm x 216.4 mm (1.73 in. x 19.00 in. x 8.52 in.), 1 U height
Weight	2.8 kg (6.17 lb)
Power specifications
Rated input voltage range (AC)	100 V to 240 V, 50 Hz/60 Hz
Maximum input voltage range (AC)	90 V AC to 264 V AC, 47 Hz to 63 Hz
Maximum output current	2 A
Maximum output power	24 W
RPS power supply	Not supported
PoE power supply	Not supported
Power consumption
Maximum power consumption	AR169F: 17.8 W AR169BF: 17.0 W
Heat dissipation
Fan module	None
Airflow (facing the front panel)	None
Interface density
Management interfaces	1 (RJ45)
CON/AUX interfaces	1 (RJ45)
USB 2.0 interfaces	1
Service interfaces (standard configuration)	WAN interfaces: one VDSL interface, and one GE combo interface LAN interfaces: four GE electrical interfaces, in which LAN interface GE0 can be configured as a WAN interface.
Extended slots	Not supported
Environment parameters
Operating temperature	0°C to 45°C (32°F to 113°F)
Storage temperature	-40°C to +70°C (-40°F to +158°F)
Operating relative humidity	5% to 95%, noncondensing
Operating altitude	< 5000 m (16404.2 ft.)
Part number	AR169F: 02356376 AR169BF: 50010210

Huawei Router AR169F AR G3 AR160 Series VDSL 1GE COMBO WAN 4GE LAN 1 USB

1	USB interface (host)	2	CON/AUX interface
3	WAN interface: GE combo interface	4	LAN interfaces: four GE electrical interfaces
5	RST button	6	Power jack
7	Jack for power cable locking strap	8	WAN interface: VDSL interface
9	Product model silkscreen	10	Ground point
